01 / 02
Product details
- Product code
- DM-301-PL
- Dimensions
- 228 × 1220 × 6 mm
- Wear layer
- 0.50 mm
- Underlay
- 1 mm IXPE
- Installation system
- UniClic
- Surface texture
- EIR
- Core
- SPC
- Use class
- Class 34
- Warranty
- Residential 20 years · Commercial 7 years
- Total thickness
- 6 mm (5 mm SPC + 1 mm IXPE)
- Core density
- 2,000 kg/m³
- Finish
- Micro-bevel, UV-cured coating
- Locking strength
- ≥ 6 kN/m (ISO 24334)
- Reaction to fire
- Bfl-s1 (EN 13501-1)
- Slip resistance
- DS (EN 13893)
- Underfloor heating
- Suitable, max. 27 °C surface
- Acoustics
- STC 75 · IIC 70
- Indoor air
- FloorScore®, VOC A+, M1, E1
Pack information
- Pieces per pack
- 7
- Coverage per pack
- 1.947 m²
- Pack weight
- 20.250 kg
- Packs per pallet
- 44
- Coverage per pallet
- 85.67 m²
- Pallet weight
- 911 kg
Ordering
- Stock
- Collection kept in stock in Istanbul
- Minimum order
- Confirmed with each quote
- Lead time
- Confirmed with each quote, by destination
Where it can be used
- Residential
- Houses, apartments, residential developments
- Hospitality
- Hotel rooms and corridors, restaurants, cafés
- Commercial
- Offices, retail stores, showrooms — up to Class 34
Application limits
- Indoor use only; floating installation with an 8–10 mm expansion gap.
- Underfloor heating: hydronic recommended, electric cable only with a surface sensor, infrared film not advised; max. 27 °C surface.
- Static load max. 30 kg/cm²; office-chair castors to EN 425 / DIN 68131.
- Acclimatise packs in the room for 48 hours at 14–30 °C before installation.
Technical documents
3 PDF
Certificates, test reports & care
Certificates
Test reports
Installation & care
Warranty
Sales support for dealers
- Samples
- Decor samples by product code
- 3D room
- Shareable visualiser with every decor
- Documentation
- TDS, CE/DoP, EPD and tests for tenders
- Imagery
- Room and decor visuals on request
Working with this collection?Samples, wholesale pricing and delivery options for your market.
Products / Diamonds
Inside the Diamonds collection
Diamonds offers ten wood-look decors in plank and herringbone formats. Its EIR texture, 0.50 mm wear layer and integrated IXPE backing give both laying patterns a consistent technical specification.
- Dimensions
- 228 × 1220 × 6 mm
- Wear layer
- 0.50 mm
- Installation system
- UniClic
